Key Features
Intel® Xeon® W-3400 series and Xeon® W-2400 series processors, Up to 350W TDP
Intel® W790
Up to 4TB(W-3400)/2TB(W-2400) 3DS ECC RDIMM, 1TB(W-3400)/512GB(W-2400) ECC RDIMM; DDR5-4800MT/s(1DPC)/ 4400MT/s(2DPC), in 16 DIMM slots
M.2 Interface: 4 PCIe 5.0 x4
M.2 Form Factor: 2280/22110
M.2 Key: M-Socket (w/o heat sink)
Xeon® W-3400 Series Processors: 6 PCIe 5.0 x16 Slots, support up to 6 Single Width/4 Double Width/2 Triple Width GPU cards Xeon® W-2400 Series Processors:3 PCIe 5.0 x16 Slots, support up to 3 Single Width/3 Double Width/2 Triple Width GPU cards (slot 3/5/7)
2 U.2 PCIe 3.0 for NVMe 2.5" SSD drives (U.2-1, U.2-2)
1GbE LAN port with Intel® Ethernet Controller I210-AT
10GbE LAN with Marvell AQC113C
8 SATA 3 (6Gb, RAID 0, 1, 5, 10)
IPMI Supported
Overclocking Supported (optional)
