Key Features
5th/4th Gen Intel® Xeon® Scalable processors, Single Socket LGA-4677 (Socket E) supported, CPU TDP supports Up to 350W TDP
Intel C741® Chipset
Up to 2TB 3DS ECC RDIMM, DDR5-5600MT/s (1DPC) in 8 DIMM slots
8 NVMe ports PCIe 5.0 x4 via 4 MCIO connectors
1 PCIe 5.0 x8,
2 PCIe 5.0 x16,
4 PCIe 5.0 x8 MCIO connectors
M.2 Interface: 2 PCIe 4.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
Dual LAN with 1GbE with Intel® I350
5 USB 3.2 Gen1 (2 rear, 1 Type-A, 2 via header), 6 USB 2.0 (2 rear, 4 via headers)
Intel® C741 controller for 10 SATA3 (6 Gbps) ports or 2 PCIe 3.0 x4 NVMe + 2 SATA3 ports; RAID (SATA) 0,1,5,10
