Key Features
1.Single AMD EPYC™ 7003/7002 Series Processor
(The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
3.Expansion slots:
5 PCI-E 4.0 x16
2 PCI-E 4.0 x8
M.2 Interface: 2 PCI-E 4.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-key
4.8 SATA3, 2 M.2,
8 SATA3 or 2 NVMe via single SlimSAS x8
5.2 Gigabit Ethernet LAN Ports
6.ASPEED AST2500 BMC graphics
7.Up to 6 USB 3.0 ports
(4 rear + 2 via header)
8.7 PWM 4-pin Fans with tachometer status monitoring
| Specifications | |
| Product SKUs | |
| MBD-H12SSL-i | H12SSL-i |
| MBD-H12SSL-i-O | H12SSL-i (Retail Pack) |
| Physical Stats | |
| Form Factor | ATX |
| Dimensions | 12" x 9.6" (30.5cm x 24.4cm) |
| Processor/Chipset | |
| CPU | Single AMD EPYC™ 7003/7002 Series Processor |
| (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer) | |
| Socket SP3 | |
| Cores | Up to 64 Cores |
| Chipset | System on Chip |
| System Memory | |
| Memory Capacity | 8 DIMM slots |
| Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM | |
| 8-channel memory bus | |
| Memory Type | DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs |
| DIMM Sizes | 8GB, 16GB, 32GB, 64GB, 128GB, 256GB |
| Memory Voltage | 1.2V |
| Error Detection | Corrects single-bit errors |
| Detects double-bit errors (using ECC memory) | |
| On-Board Devices | |
| SATA | SATA3 (6 Gbps) |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | |
| ASPEED AST2500 BMC | |
| Network Controllers | Dual gigabit LAN via Broadcom BCM5720 |
| 1 Realtek RTL8211F PHY (dedicated IPMI) | |
| VGA | ASPEED AST2500 BMC |
| Input / Output | |
| SATA | 8 SATA3 (6 Gbps) ports |
| SATA/NVMe Hybrid | 8 SATA3 or 2 NVMe via single SlimSAS x8 |
| LAN | 2 RJ45 Gigabit Ethernet LAN ports |
| 1 RJ45 Dedicated IPMI LAN port | |
| USB | 6 USB 3.0 ports |
| (4 rear + 2 via header) | |
| VGA | 1 VGA port |
| Others | 1 COM port (rear) |
| 2 SATA DOM power connectors | |
| 1 TPM 2.0 header | |
| Expansion Slots | |
| PCI-Express | 5 PCI-E 4.0 x16 |
| 2 PCI-E 4.0 x8 | |
| M.2 | Interface: 2 PCI-E 4.0 x4 |
| Form factor: 2280, 22110 | |
| Key: M-key | |
| Chassis ( Optimized for H12SSL-i ) | |
| 1U | SC813MFTQC-350CB2 |
| SC813MFTQC-R407CB | |
| 2U | SC213BAC8-R1K23LPB |
| SC216BE1C4-R1K23LPB | |
| SC825MBTQC-R802LPB | |
| SC825TQC-R802LPB | |
| SC826BE1C4-R1K23LPB | |
| SCLA26AC12-R920LP1 | |
| 3U | SC835TQC-R802B |
| SC836BE1C-R1K23B | |
| Mid-Tower | SC732i-903B |
| Tower/4U | SC745BAC-R1K23B |
| SC846BE1C-R1K23B | |
| Server(s) ( with H12SSL-i ) | |
| Model(s) | AS -2014S-TR |
| AS -3014TS-i | |
| System BIOS | |
| BIOS Type | AMI 256Mb SPI Flash EEPROM |
| BIOS Features | Plug and Play (PnP) |
| DMI 2.3 | |
| PCI 2.2 | |
| ACPI 5.1 | |
| USB Keyboard Support | |
| SMBIOS 3.1.1 | |
| Management | |
| Software | Super |
 Doctor 5 | |
| Watch Dog | |
| NMI | |
| SUM | |
| IPMI 2.0, KVM with dedicated LAN | |
| Power Configurations | ACPI Power Management |
| Power-on mode control for AC power loss recovery | |
| PC Health Monitoring | |
| CPU | Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby |
| CPU switching voltage regulator | |
| Supports system management utility | |
| VBAT | |
| FAN | Up to 7-fan status tachometer monitoring |
| Up to 7 4-pin fan headers | |
| Dual Cooling Zone | |
| Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | |
| Temperature | Monitoring for CPU and chassis environment |
| CPU Thermal Trip Support | |
| Thermal control for 7x Fan connectors | |
| I²C Temperature Sensing Logic | |
| LED | CPU / System Overheat LED |
| Other Features | Chassis Intrusion Detection |
| Chassis Intrusion Header | |
| UID | |
| Operating Environment / Compliance | |
| Environmental Specifications | Operating Temperature: |
| 10°C to 35°C (50°F to 95°F) | |
| Non-operating Temperature: | |
| -40°C to 70°C (-40°F to 158°F) | |
| Operating Relative Humidity: | |
| 8% to 90% (non-condensing) | |
| Non-operating Relative Humidity: | |
| 5% to 95% (non-condensing) | |
| Parts List | |||
| Bulk Pack List | |||
| Part Number | Qty | Description | |
| H12SSL-i | MBD-H12SSL-i-B | 1 | H12SSL-i Motherboard |
| I/O Cable | CBL-0044L | 2 | 57.5CM SATA FLAT S-S PBF |
| I/O Shield | MCP-260-00042-0N | 1 | STD I/O SHIELD FOR X9 SOCKET R SERVER MB |
| Retail Pack List | |||
| Part Number | Qty | Description | |
| H12SSL-i | MBD-H12SSL-i-O | 1 | H12SSL-i Motherboard |
| I/O Cable | CBL-0044L | 6 | 57.5CM SATA FLAT S-S PBF |
| I/O Shield | MCP-260-00042-0N | 1 | STD I/O SHIELD FOR X9 SOCKET R SERVER MB |
| Optional Parts List | |||
| Part Number | Qty | Description | |
| I/O Cable | CBL-SAST-0699 | - | MINI SAS HD-4 SATA,12G,INT,75/75/90/90CM,75CM SB,28/30AWG,Ro |
| TPM security module | AOM-TPM-9655V | - | TPM 1.2 module with Infineon 9655, RoHS/REACH,PBF; |
| AOM-TPM-9665V | - | TPM 2.0 module with Infineon 9665, RoHS/REACH,PBF; | |
