Key Features
3rd Gen Intel® Xeon® Scalable processors, Dual Socket LGA-4189 (Socket P+) supported, CPU TDP supports Up to 270W TDP, 3 UPI up to 11.2 GT/s
Intel® C621A
Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SSM, SUM, SuperDoctor® 5, Watchdog
Up to 4TB 3DS ECC RDIMM, DDR4-3200MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-3200MHz
Up to 6TB Intel® Optane™ Persistent Memory 200 Series, in 16 DIMM slots;
Up to 6TB Intel® Optane™ DC Persistent Memory in memory mode.
6 PCIe 4.0 x16,
1 PCIe 4.0 x8
M.2 Interface: 2 PCIe 4.0 x4, RAID 0 & 1
M.2 Form Factor: 2242/2260/2280/22110
M.2 Key: M-Key
Dual LAN with Intel® X550 10GBase-T Ethernet Controller
Integrated IPMI 2.0 and KVM with Dedicated LAN
5 USB 3.0 ports, 4 USB 2.0 ports
HD Audio with optical S/PDIF
