Key Applications：
•Scientific Virtualization
•High Performance Computing
•Rendering
•AI/Deep Learning Training
Key Features：
1. Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
2. Intel® C621A Chipset
3. 16 DIMM Slots; Up to 4TB DRAM; Up to 6TB Intel® Optane™ Persistent Memory ; 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series
4. 4 PCIe 4.0 x16 (double-width) slots, 2 PCIe 4.0 x16 (single-width) slots,1 PCIe 4.0 x8 LP
5.Total 8x 3.5" Hot-swap drive bays
Up to 8 NVMe drives (4 NVMe drives supported by default)
2 M.2 NVMe or SATA for boot drive only
6.4 Removable heavy duty fans w/ Optimal Fan Speed Control
7.2x 2200W redundant Titanium level power supplies
| Product SKUs | |
| SuperServer SYS-740GP-TNRT | |
| Motherboard | |
| Super X12DPG-QT6 | |
| Processor | |
| CPU | Dual Socket P+ (LGA-4189) |
| 3rd Gen Intel® Xeon® Scalable processors | |
| Core Count | Up to 40C/80T; Up to 60MB Cache per CPU |
| Note | Supports up to 270W TDP CPUs (Air Cooled) |
| GPU | |
| Max GPU Count | Up to 4 double-width or 6 single-width GPU(s) |
| Supported GPU | NVIDIA PCIe: A40, RTX A5000, RTX A4000, A30, A100, RTX A6000, RTX A4500, A40, A16, A10 |
| View GPU Options | |
| CPU-GPU Interconnect | PCIe 4.0 x16 CPU-to-GPU Interconnect |
| GPU-GPU Interconnect | PCIe |
| Certification |  |
| System Memory | |
| Memory | Slot Count: 16 DIMM slots |
| Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM | |
| Supports Intel® Optane™ persistent memory 200 series | |
| View Memory Options | |
| Memory Voltage | 1.2V |
| On-Board Devices | |
| SATA | SATA (6Gbps) ; RAID 0/1/5/10 support |
| Chipset | Intel® C621A |
| Network Connectivity | 2 RJ45 10GbE with Intel® X550-AT2 |
| View AOC Options | |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| IPMI 2.0 with virtual media over LAN and KVM-over-LAN support | |
| NVMe | View NVMe Options |
| Input / Output | |
| Video | 1 VGA port(s) |
| System BIOS | |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Management | |
| Software | Redfish API |
| Supermicro Server Manager (SSM) | |
| Supermicro Power Manager (SPM) | |
| Supermicro Update Manager (SUM) | |
| SuperDoctor® 5 | |
| Super Diagnostics Offline | |
| KVM with dedicated LAN | |
| IPMI 2.0 | |
| Power configurations | Power-on mode for AC power recovery |
| ACPI Power Management | |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 |
| Silicon Root of Trust (RoT) – NIST 800-193 Compliant | |
| Features | Cryptographically Signed Firmware |
| Secure Boot | |
| Secure Firmware Updates | |
| Automatic Firmware Recovery | |
| System Lockdown | |
| PC Health Monitoring | |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory |
| 7 +1 Phase-switching voltage regulator | |
| FAN | Fans with tachometer monitoring |
| Status monitor for speed control | |
| Pulse Width Modulated (PWM) fan connectors | |
| Temperature | Monitoring for CPU and chassis environment |
| Thermal Control for fan connectors | |
| Chassis | |
| Form Factor | Full-Tower |
| Model | CSE-747BTS-R2K20BP |
| Dimensions and Weight | |
| Height | 18.1" (460 mm) |
| Width | 7" (178 mm) |
| Depth | 26.5" (673 mm) |
| Package | 12.7" (H) x 27" (W) x 37.5" (D) |
| Weight | Gross Weight: 57 lbs (25.85 kg) |
| Net Weight: 52.9 lbs (24 kg) | |
| Available Color | black |
| Front Panel | |
| LED | HDD activity |
| Network activity | |
| Power On | |
| System Overheat / Fan Fail LED | |
| Buttons | Power On/Off |
| System Reset | |
| Expansion Slots | |
| PCI-Express (PCIe) Configuration | Default |
| 4 PCIe 4.0 x16 FHFL slot(s) | |
| 2 PCIe 4.0 x16 LP slot(s) | |
| 1 PCIe 4.0 x8 LP slot(s) | |
| View AOC Options | |
| Drive Bays / Storage | |
| Drive Bays Configuration | Default: Total 8 bay(s) |
| 4 front hot-swap 3.5" SAS/SATA drive bay(s) | |
| 4 front hot-swap 3.5" NVMe/SAS/SATA drive bay(s) | |
| View Drive Options | |
| M.2 | 2 M.2 NVMe/SATA slot(s) (M-key) |
| View M.2 Options | |
| Peripheral Bays | 3 5.25" peripheral bay(s) |
| System Cooling | |
| Fans | 4 heavy duty fans with optimal fan speed control |
| Power Supply | |
| 2200W Redundant Titanium Level power supplies | |
| Dimension (WxHxL) | 76 x 40 x 336 mm |
| +12V | Max: 100A / Min: 0A (100Vac-127Vac) |
| Max: 150A / Min: 0A (200Vac-220Vac) | |
| Max: 165A / Min: 0A (220Vac-230Vac) | |
| Max: 183.33A / Min: 0A (220Vac-240Vac) (for UL/cUL only) | |
| Max: 174.17A / Min: 0A (230Vac-240Vac) | |
| Max: 174.17A / Min: 0A (230Vdc-240Vdc) (for CCC only) | |
| Max: 174.17A / Min: 0A (230Vac-240Vac) (for UL/cUL only) | |
| 5V SB | Max: 1A / Min: 0A |
| AC Input | 1200W: 100-127Vac / 50-60Hz |
| 1800W: 200-220Vac / 50-60Hz | |
| 2090W: 200-220Vac / 50-60Hz (for UL/cUL use only) | |
| 1980W: 220-230Vac / 50-60Hz | |
| 2200W: 220-240Vac / 50-60Hz (for UL/cUL use only) | |
| 2090W: 230-240Vac / 50-60Hz | |
| 2090W: 230-240Vdc / 50-60Hz (for CCC only) | |
| Output Type | Backplanes (gold finger) |
| Operating Environment | |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) |
| Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) | |
| Operating Relative Humidity: 8% to 90% (non-condensing) | |
| Non-operating Relative Humidity: 5% to 95% (non-condensing) | |
<td class="spec border_br" background="https://www.supermicro.org.cn/en/products/system/gpu/4u/sys-740gp-tnrt?_gl=1*1ai33gn*_ga*Mzg0MTA4ODA1LjE3MDkxMDA1NDg.*_ga_K1TNNPLV4M*MTcwOTI4OTYyNS4xMC4xLjE3MDkyOTUyMzIuNTUuMC4w" style="box-sizing: border-box; color: rgb(0, 51, 153); border-width: init
<td class="spec border_br align-left" background="https://www.supermicro.org.cn/en/products/system/gpu/4u/sys-740gp-tnrt?_gl=1*1ai33gn*_ga*Mzg0MTA4ODA1LjE3MDkxMDA1NDg.*_ga_K1TNNPLV4M*MTcwOTI4OTYyNS4xMC4xLjE3MDkyOTUyMzIuNTUuMC4w" style="box-sizing: border-box; color: rgb(0, 51, 153); border-width: initial; border-style: none; border-color: initial; line-height: 1.2; vertical-align: top; float: left; text-align: right; padding-top: 3px !important; padding-botto
| Standard Parts (Parts Included) | |||
| Part Number | Qty | Description | |
| Motherboard / Chassis | MBD-X12DPG-QT6 CSE-747BTS-R2K20BP | 1 1 | Super X12DPG-QT6 Motherboard Full-Tower Chassis |
| Backplane | BPN-NVME4-747N-S8 | 1 | 8-port 3.5" HDD/NVMe backplane for 4U Tower chassis, all 8 ports support NVMe Gen4 / SAS / SATA devices.,RoHS |
| Cable | CBL-PWCD-0900 | 2 | PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17 |
| CBL-PWEX-1040 | 4 | PWYCB,GPU,2x4M/CPU to two (2x3F+2x1F)/PCIe,P4.2, 5CM,16/20AW | |
| CBL-SAST-1230-100 | 2 | Slimline x4 (LE) to Slimline x4 (STR),INT,30CM,100 OHM, | |
| CBL-SAST-1230-85 | 2 | Slimline x8 (LE) to Slimline x8 (RE),INT,30CM,85 OHm,R | |
| CBL-0071L | 1 | ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF | |
| CBL-0160L | 2 | US POWER CORD 16AWG, PB FREE | |
| CBL-0216L | 4 | 4 TO 4 PIN FAN POWER CABLE, 210MM | |
| CBL-0286L | 2 | 4 TO 4 PIN REAR FAN PWR EXT W/ SQUARE HEADER, 30CM (PWM) | |
| Drive Tray(s) | MCP-220-00150-0B | 4 | NVMe Panetone 159C on Latch |
| MCP-220-00073-0B | 3 | Black 5.25 drive tray w/o rail (SC747) | |
| Parts | MCP-260-00150-0N | 1 | STD I/O Shield for X12DPG-QT with EMI Gasket |
| MCP-290-74701-0B | 1 | Black plastic top cover for SC747 | |
| MCP-290-74702-0N | 1 | GPU Card Holder (11 slots) for SC747TQ, SC842 | |
| MCP-290-74703-0B | 1 | fixed 3.5" dummy cover for SC747 | |
| MCP-290-74709-0B | 1 | Plastic feet (2 pcs/set) for 4U tower chassis, black color | |
| Software | SFT-OOB-LIC | 1 | License key for enabling OOB BIOS management |
| Heatsink / Retention | SNK-P0080AP4 | 2 | 4U Active CPU Heat Sink for X12 Generation DP Workstations and 4U Servers |
| *Power Supply | PWS-2K20A-1R | 2 | 1U 2200W Redundant, Titanium, 76(W) X 40(H) X 336(L) mm |
| *Power Distributor | PDB-PT747-6824 | 1 | Power Distributor Board is for 4U GPU solution using regular |
| *Fan | FAN-0082L4 | 2 | 80x80x38 mm 4-pin PWM Fan Assembly for SC743, SC745 |
