Key Features:
1.2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors, , Dual Socket LGA-3647
(Socket P) supported, CPU TDP support Up to 205W TDP, 3 UPI up to 10.4 GT/s
2.Intel® Node Manager, IPMI2.0, KVM with dedicated LAN, NMI, SPM, SSM, SUM, SuperDoctor® 5, Watchdog
3.Intel® C621
4.Up to 4TB 3DS ECC RDIMM, DDR4-2933MHz; Up to 4TB 3DS ECC LRDIMM, DDR4-2933MHz
Or 2TB DCPMM, DDR4-2666MHz, in 16 DIMM slots;
Up to 2TB Intel® Optane™ DC Persistent Memory in memory mode (Cascade Lake only).
5.6 PCIe 3.0 x16,
1 PCIe 3.0 x4 (in x8 slot)
M.2 Interface: PCIe 3.0 x4
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
6.Dual LAN with Intel® X550 10GBase-T Ethernet Controller
7.Intel® C621 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
8.Integrated IPMI 2.0 and KVM with Dedicated LAN
9.5 USB 3.0 ports, 4 USB 2.0 ports
10.HD Audio with optical S/PDIF
