Key Features
AMD Ryzen™ 7000 series Processors, single socket LGA-1718 (socket AM5) supported
TDP supports up to 170W.
Up to 192GB ECC/non-ECC Unbuffered DIMM, DDR5-5200MHz, in 4 DIMM slots.
2 PCIe 5.0 x16 (16/NA or 8/8), support up to 2 GPU cards(mechanical is up to 1 triple-width GPU card or 2 double-width GPU cards)
1 PCIe 4.0 x4
2x 1Gbit LAN port(i210 AT); a dedicated Realtek 1Gbit LAN for IPMI.
Micro-ATX form factor
1 USB 3.2 Gen2x2 ports (type C, 20Gb, rear); 5 USB 3.2 Gen2 ports(2 Type C, rear, support DP 1.4 Alt mode)
1 HDMI 2.0 port, 1 DP 1.4a port
M.2 Interface: 2 PCIe 5.0 x4 (RAID 0 & 1)
M.2 Form Factor: 2280/22110
M.2 Key: M-Key
