1 - Up to 4K 12-bit HDR at 240Hz with DP 1.4a + DSC or HDMI 2.1a + DSC. Up to 8K 12-bit HDR at 60Hz with DP 1.4a + DSC or HDMI 2.1a + DSC.
2 - As specified in HDMI 2.1a: up to 4K 240Hz or 8K 60Hz with DSC, Gaming VRR, HDR
3 - DisplayPort 1.4a
4 - Multi Monitor:
4 independent displays at 4K 120Hz using DP or HDMI
2 independent displays at 4K 240Hz or 8K 60Hz with DSC using DP or HDMI
Other display configurations may be possible based on available bandwidth
5 - Idle power measured with GPU running at idle at the Windows desktop for 10 minutes
6 - Video playback power measured using AV1 codec
7 - Average gaming power is measured across 22 games at 4K, 1440p, and 1080p
8 - Minimum is based on a PC configured with a Ryzen 9 5900X processor. Power requirements can be different depending on system configuration.
| GPU Engine Specs: | NVIDIA CUDA Cores® | 16384 |
| Shader Cores | Ada Lovelace 83 TFLOPS | |
| Ray Tracing Cores | 3rd Generation 191 TFLOPS | |
| Tensor Cores (AI) | 4th Generation 1321 AI TOPS | |
| Boost Clock (GHz) | 2.52 | |
| Base Clock (GHz) | 2.23 | |
| Memory Specs: | Standard Memory Config | 24 GB GDDR6X |
| Memory Interface Width | 384-bit | |
| Technology Support: | NVIDIA Architecture | Ada Lovelace |
| Ray Tracing | Yes | |
| NVIDIA DLSS | DLSS 3.5 Super Resolution DLAA Ray Reconstruction Frame Generation | |
| NVIDIA Reflex | Yes | |
| NVIDIA Broadcast | Yes | |
| PCI Express Gen 4 | Yes | |
| Resizable BAR | Yes | |
| NVIDIA GeForce Experience®™ | Yes | |
| NVIDIA Ansel | Yes | |
| NVIDIA FreeStyle | Yes | |
| NVIDIA ShadowPlay | Yes | |
| NVIDIA Highlights | Yes | |
| NVIDIA G-SYNC® | Yes | |
| Game Ready Drivers | Yes | |
| NVIDIA Studio Drivers | Yes | |
| NVIDIA Omniverse | Yes | |
| Microsoft DirectX 12 Ultimate® | Yes | |
| NVIDIA GPU Boost™ | Yes | |
| NVIDIA NVLink™ (SLI-Ready) | No | |
| Vulkan RT API, OpenGL 4.6 | Yes | |
| NVIDIA Encoder (NVENC) | 2x 8th Generation | |
| NVIDIA Decoder (NVDEC) | 5th Generation | |
| AV1 Encode | Yes | |
| AV1 Decode | Yes | |
| CUDA Capability | 8.9 | |
| VR Ready | Yes | |
| Display Support: | Maximum Resolution & Refresh Rate (1) | 4K at 240Hz or 8K at 60Hz with DSC, HDR |
| Standard Display Connectors | HDMI(2), 3x DisplayPort(3) | |
| Multi Monitor | up to 4(4) | |
| HDCP | 2.3 | |
| Card Dimensions: | Length | 304 mm |
| Width | 137 mm | |
| Slots | 3-Slot (61mm) | |
| Thermal and Power Specs: | Maximum GPU Temperature (in C) | 90 |
| Idle Power (W) (5) | 19 | |
| Video Playback Power (W) (6) | 25 | |
| Average Gaming Power (W) (7) | 315 | |
| Total Graphics Power (W) | 450 | |
| Required System Power (W) (8) | 850 | |
| Supplementary Power Connectors | 3x PCIe 8-pin cables (adapter in box) OR 450 W or greater PCIe Gen 5 cable |
