GeForce RTX 4080 Series

1 - Supports 4K 12-bit HDR display at up to 240Hz with DP 1.4a and DSC or HDMI 2.1a and DSC. With DP 1.4a and DSC technology, or HDMI 2.1a and DSC technology, it can support 8K 12-bit HDR display at up to 60Hz.

2 - HDMI 2.1a compliant: DSC supports HDR displays and variable refresh rate gaming at up to 4K 240Hz or 8K 60Hz

3 - DisplayPort 1.4a

4 - Number of multiple monitors supported:

With DP or HDMI connector, it can support 4 independent displays at 4K 120Hz
With DP or HDMI and DSC support, it supports 2 independent displays at 4K 240Hz or 8K 60Hz
According to the actual allocation of display bandwidth, it is compatible with more display configuration schemes of different specifications
5 - Idle power consumption is based on GPU testing after 10 minutes of running in the Windows desktop idle state.

6 - Video playback power consumption is based on testing with the AV1 decoder.

7 - Typical game power consumption is based on a combination of 22 games tested at 4K, 1440p and 1080p.

8 - Minimum system power required is based on recommendations for PCs with Ryzen 9 5900X processors. The actual required power depends on the specific system configuration.

邮箱

GPU Engine Specifications:
Number of NVIDIA CUDA Cores®	10240	9728
Shader Core	Ada Lovelace 52 TFLOPS	Ada Lovelace 49 TFLOPS
RT Core	3rd generation 121 TFLOPS	3rd generation 113 TFLOPS
Tensor Core (AI)	4th Gen 836 AI TOPS	4th Gen 780 AI TOPS
Boost Frequency (GHz)	2.55	2.51
Base Frequency (GHz)	2.29	2.21

Video Memory Specifications:
Standard memory configuration	16 GB GDDR6X	16 GB GDDR6X
The memory bit width	256 bits	256 bits

Technical Support:
NVIDIA architecture	Ada Lovelace	Ada Lovelace
Ray tracing is supported	be	be
NVIDIA DLSS is supported	DLSS 3.5 Super Resolution DLAA ray reconstruction frame generation	DLSS 3.5 Super Resolution DLAA ray reconstruction frame generation
NVIDIA Reflex is supported	be	be
NVIDIA Broadcast is supported	be	be
PCI Express Gen 4 is supported	be	be
Resizable BAR is supported	be	be
Support for NVIDIA GeForce Experience®™	be	be
NVIDIA Ansel is supported	be	be
NVIDIA FreeStyle is supported	be	be
NVIDIA ShadowPlay is supported	be	be
Support for NVIDIA Highlights	be	be
Support for NVIDIA G-SYNC®	be	be
Game Ready Driver support	be	be
NVIDIA Studio drivers are supported	be	be
NVIDIA Omniverse support	be	be
Microsoft DirectX 12 Ultimate is supported®	be	be
NVIDIA GPU Boost is supported™	be	be
NVIDIA NVLink is supported™ (SLI-Ready)	not	not
Support for Vulkan RT API, OpenGL 4.6	be	be
NVIDIA Encoder (NVENC)	2x Gen 8	2x Gen 8
NVIDIA Decoder (NVDEC)	5th generation	5th generation
AV1 encoding	be	be
AV1 decoding	be	be
CUDA capabilities	8.9	8.9
VR Ready is supported	be	be

Display support:
Highest digital resolution and refresh rate(1)	Display HDR at 4K 240Hz or 8K 60Hz with DSC support	Display HDR at 4K 240Hz or 8K 60Hz with DSC support
Standard monitor interface	HDMI(2), 3 DisplayPort ports(3)	HDMI(2), 3 DisplayPort ports(3)
Multiple monitors	Up to 4(4)	Up to 4(4)
HDCP	2.3	2.3

Graphics card size:
length	304 mm	304 mm
width	137 mm	137 mm
slot	3 slots	3 slots

Temperature & Power Specifications:
Maximum GPU Temperature (°C)	90	90
Idle Power Consumption (Watts) (5)	15	13
Video Playback Power Consumption (Watts) (6)	22	21
Typical Game Power Consumption (Watts) (7)	246	251
Total Graphics Card Power Consumption (Watts)	320	320
Required System Power (Watts) (8)	750	750
Auxiliary power connector	3 x PCIe 8-pin cables (adapter included) or 1 PCIe Gen 5 power cable with 450W and higher power ratings.	3 x PCIe 8-pin cables (adapter included) or 1 PCIe Gen 5 power cable with 450W and higher power ratings.
