| GPU Engine Specifications: |
|
|
| Number of NVIDIA CUDA Cores® | 10240 | 9728 |
| Shader Core | Ada Lovelace
52 TFLOPS | Ada Lovelace
49 TFLOPS |
| RT Core | 3rd generation
121 TFLOPS | 3rd generation
113 TFLOPS |
| Tensor Core (AI) | 4th Gen
836 AI TOPS | 4th Gen
780 AI TOPS |
| Boost Frequency (GHz) | 2.55 | 2.51 |
| Base Frequency (GHz) | 2.29 | 2.21 |
|
|
|
| Video Memory Specifications: |
|
|
| Standard memory configuration | 16 GB GDDR6X | 16 GB GDDR6X |
| The memory bit width | 256 bits | 256 bits |
|
|
|
| Technical Support: |
|
|
| NVIDIA architecture | Ada Lovelace | Ada Lovelace |
| Ray tracing is supported | be | be |
| NVIDIA DLSS is supported | DLSS 3.5
Super Resolution
DLAA
ray reconstruction
frame generation | DLSS 3.5
Super Resolution
DLAA
ray reconstruction
frame generation |
| NVIDIA Reflex is supported | be | be |
| NVIDIA Broadcast is supported | be | be |
| PCI Express Gen 4 is supported | be | be |
| Resizable BAR is supported | be | be |
| Support for NVIDIA GeForce Experience®™ | be | be |
| NVIDIA Ansel is supported | be | be |
| NVIDIA FreeStyle is supported | be | be |
| NVIDIA ShadowPlay is supported | be | be |
| Support for NVIDIA Highlights | be | be |
| Support for NVIDIA G-SYNC® | be | be |
| Game Ready Driver support | be | be |
| NVIDIA Studio drivers are supported | be | be |
| NVIDIA Omniverse support | be | be |
| Microsoft DirectX 12 Ultimate is supported® | be | be |
| NVIDIA GPU Boost is supported™ | be | be |
| NVIDIA NVLink is supported™ (SLI-Ready) | not | not |
| Support for Vulkan RT API, OpenGL 4.6 | be | be |
| NVIDIA Encoder (NVENC) | 2x Gen 8 | 2x Gen 8 |
| NVIDIA Decoder (NVDEC) | 5th generation | 5th generation |
| AV1 encoding | be | be |
| AV1 decoding | be | be |
| CUDA capabilities | 8.9 | 8.9 |
| VR Ready is supported | be | be |
|
|
|
| Display support: |
|
|
| Highest digital resolution and refresh rate(1) | Display HDR at 4K 240Hz or 8K 60Hz with DSC support | Display HDR at 4K 240Hz or 8K 60Hz with DSC support |
| Standard monitor interface | HDMI(2), 3 DisplayPort ports(3) | HDMI(2), 3 DisplayPort ports(3) |
| Multiple monitors | Up to 4(4) | Up to 4(4) |
| HDCP | 2.3 | 2.3 |
|
|
|
| Graphics card size: |
|
|
| length | 304 mm | 304 mm |
| width | 137 mm | 137 mm |
| slot | 3 slots | 3 slots |
|
|
|
| Temperature & Power Specifications: |
|
|
| Maximum GPU Temperature (°C) | 90 | 90 |
| Idle Power Consumption (Watts) (5) | 15 | 13 |
| Video Playback Power Consumption (Watts) (6) | 22 | 21 |
| Typical Game Power Consumption (Watts) (7) | 246 | 251 |
| Total Graphics Card Power Consumption (Watts) | 320 | 320 |
| Required System Power (Watts) (8) | 750 | 750 |
| Auxiliary power connector | 3 x PCIe 8-pin cables (adapter included)
or
1 PCIe Gen 5 power cable with 450W and higher power ratings. | 3 x PCIe 8-pin cables (adapter included)
or
1 PCIe Gen 5 power cable with 450W and higher power ratings. |
